Technical Characteristics
| Brand | HI-LUX |
| Product Type | Head Lamp |
| Voltage | 12V |
| Source | HS1 Bulb 35/35W P43T (Phoenix) |
| Consumption | 35/35W |
| Color | White |
| Light pattern | Low & high beam |
| Housing | CRCA, Delphinium Blue |
| Connector | C-090-1PFNY & C-090-2PFNY |
| Mounting | M14 Bolt |
| Lens Material | Glass |
| Shape | Round |
| Width | 157 mm |
| Reflector | PC, Al. Metalized |
| Weight | |
| IP protection | IP55 |
| Operation Temperatures | -40°C to +85°C |
| Salt Spray Test | For red rust 240hrs & for white rust 120hrs |
| Vibration Resistance | Vibration level 4.5 to 5.0G |
| EMC | NA |
| Industry | Automotive |
